Copper Mining in Northern Ontario
- Sylvia Rose
- Aug 3
- 9 min read
Updated: Aug 7
Copper mining in North Ontario is a vital part of local economy and the global copper supply chain. This region of boreal forest, ancient rock and sparkling lakes is rich in natural resources.
Copper is one of the main elements found in nature, and one of the seven ancient metals. It's common in minerals like chalcopyrite, bornite, and malachite.
In Northern Ontario, substantial copper deposits appear in Precambrian rock formations. These areas, like the Superior province, consist mainly of igneous and metamorphic rocks.
Over millions of years copper is created through geological processes such as volcanic activity and rock erosion. Copper deposits are linked to magmatic activity.
As molten rock or magma cools and crystallizes, certain minerals become concentrated. These processes happen where oxygen and sulfur abound, and heat and pressure create the conditions for copper ores to form.
Copper deposits are driven primarily by hydrothermal activity. This occurs when superheated water, abundant in dissolved minerals, circulates through the Earth's crust.
As these fluids cool or encounter changes in pressure and chemistry, the dissolved metals, including copper, precipitate out. They're deposited in cracks, faults and porous rock.
When the magma interacts with groundwater, it creates perfect conditions for hydrothermal circulation to deposit copper. The processes can take millions of years and creates vast ore bodies deep within the Earth.
Copper Environments and Rock Types in Northern Ontario
In North Ontario, copper is most abundantly found in the Sudbury Basin region. A massive meteorite impact event nearly two billion years ago formed this unique geological structure.
It's one of the world's richest polymetallic deposits. Besides copper this region yields significant quantities of nickel, platinum group metals (PGMs), gold and silver. It's a geological environment of ancient volcanic arcs, intrusive complexes, or, in Sudbury's case, an impact-modified magmatic sulfide system.
Copper here is associated with mafic and ultramafic igneous rocks, rich in iron and magnesium, like norite and gabbro; and heavily metamorphosed stone. Host ores often contain sulfide minerals, with copper frequently found near nickel, in minerals like chalcopyrite (copper iron sulfide) and pentlandite (nickel iron sulfide).
The Quest for Ore: Locating a New Mine
Before a single shovel touches the ground, mining companies embark on an intensive and costly exploration journey to determine the location of a new mine. This process involves several stages:
Prospecting & Regional Surveys: Geologists begin by analyzing historical data, satellite imagery, and aerial photographs for geological patterns that suggest mineralization. Seismic and aerial geophysical surveys can detect anomalies beneath the surface.
Ground-Based Exploration: Once promising areas are identified, ground teams conduct detailed geological mapping, rock chip sampling, soil geochemistry (analyzing trace elements in soil), and more detailed geophysical surveys to pinpoint potential ore bodies.
Drilling: Diamond drill rigs extract cylindrical core samples from varying depths. The cores are then analyzed in laboratories to determine the presence, concentration or grade, and extent of mineral deposits.
Resource Estimation: Based on drilling results, geologists create 3D models of the ore body, estimating the total tonnage and average grade of the mineral deposit.
Feasibility Studies: Before committing to construction, comprehensive studies assess the economic viability, engineering challenges, environmental impacts, and social license or community acceptance of the proposed mine. This includes market analysis, infrastructure needs, and projected costs versus revenue.
Environmental assessments are crucial. They ensure potential mining activities don't harm local ecosystems. Mining companies must evaluate the impact of operations on wildlife habitats, water sources, and air quality.
Beneath and Above: Mining Methods
Once an ore body is confirmed, mining companies choose the most appropriate extraction method based on the deposit's depth, shape, size, and grade.
Surface Mining (Open-Pit Mining): This method is used when the ore body is relatively shallow and widespread. Large areas of waste rock and soil, called overburden, are removed to expose the ore.
Process: Blasting loosens the rock. Massive electric shovels load the broken ore and waste rock into colossal haul trucks, which transport them to crushers or waste dumps. The pit deepens in benches or terraces as mining progresses.
Advantages: Generally safer, lower cost per ton, allows for higher production volumes.
Disadvantages: Large surface footprint, significant visual impact, requires massive equipment. It can lead to significant alterations to the landscape. Areas around Sudbury, Ontario have been transformed due to extensive open-pit operations.
Underground Mining: Employed when the ore body is too deep or too narrow for surface mining.
Process: Access to the ore is through vertical shafts, for hoisting ore and personnel; or inclined ramps for vehicle access. Tunnels (drifts and crosscuts) are driven to intersect the ore body.
Blasting breaks up the ore. It's then loaded onto underground trucks or rail cars and transported to the shaft and taken to the surface. Various specific methods (e.g., cut-and-fill, room-and-pillar, block caving) are chosen based on the ore body's characteristics.
Advantages: Smaller surface footprint, less waste rock to manage on the surface, can access higher-grade, deeper deposits.
Disadvantages: More complex, higher operating costs, greater safety challenges including ventilation, ground support and confined spaces; significantly slower production rates.
In Northern Ontario, especially in the Sudbury Basin, both surface and extensive underground operations are common due to the varied nature of the ore bodies.
From Ore to Metal: Extraction and Processing
Copper extraction involves several steps. Initially, the ore is crushed into smaller pieces, making it easier to process. Then, the ore undergoes concentration, often using methods like flotation, where chemicals separate the copper from waste materials.
After the concentration process, the copper concentrate is smelted at high temperatures to eliminate impurities. The molten copper is then shaped into anodes, which are further refined through electrolysis to produce pure copper.
Milling & Concentration
Crushing: Large chunks of ore are fed into primary and secondary crushers, reducing them to smaller, manageable sizes.
Grinding: The crushed ore is then ground into a fine powder or slurry in large rotating mills such as ball mills or SAG mills.
Flotation: This is the most common method for concentrating copper sulfides. The ore slurry is mixed with water, frothing agents, and chemical collectors.
Air is blown through the mixture, causing the copper-bearing minerals to attach to air bubbles and float to the surface, forming a froth. The waste material or gangue sinks. The froth is skimmed off, creating a concentrate typically 25-30% copper.
Smelting: The copper concentrate is often roasted and fed into a smelter.
Process: In flash furnaces or other types of smelters, the concentrate is heated to extremely high temperatures. This process removes iron and sulfur.
Iron and sulfur combine with oxygen to form sulfur dioxide (SO2), now often captured for sulfuric acid production. SO2 leaves behind a molten mixture called matte, which is primarily copper, nickel, and iron sulfides.
Further refining in converters removes more impurities. This produces blister copper, which is 98-99% pure.
Refining (Electrolytic Refining):
Process: Blister copper is cast into large anodes. These anodes are then immersed in an electrolytic solution (e.g., copper sulfate and sulfuric acid), along with thin sheets of pure copper called cathodes. When an electric current is passed through the solution, copper from the anode dissolves and preferentially plates onto the pure copper cathodes, leaving impurities behind.
Result: This process yields high-purity copper cathodes (over 99.99% pure), ready for manufacturing into wire, pipe, or other products.
The Human Element: Life in a Mine Community
Mining is a cornerstone of Northern Ontario's economy, employing thousands of people directly and indirectly.
Employment: A large, integrated mine, smelter and refinery complex can employ anywhere from 1,000 to 5,000 or more people. Smaller operations might employ a few hundred. These roles range from engineers and geologists to skilled trades (mechanics, electricians), drillers, blasters, equipment operators, and administrative staff.
Worker Conditions: Modern mining prioritizes safety. However, the work remains physically demanding, often hot, dusty, noisy, and potentially dangerous, especially underground. Shifts can be long, often rotating (day/night). Workers must adhere to strict safety protocols and wear extensive personal protective equipment (PPE).
Housing and Community: Historically, mining companies built entire "company towns" in remote areas to house their employees, providing everything from churches and schools to recreation facilities (e.g., Copper Cliff in Sudbury, Timmins).
Expenses like groceries and rent would often be docked from a worker's pay, as told in the wailing blues lyric "I owe my soul to the company store" (Sixteen Tons, Tennessee Ernie Ford). While new "company towns" are less common today, established mining communities like Sudbury, Timmins, and Kirkland Lake still thrive on the back of the industry.
In remote areas, companies may operate fly-in/fly-out camps with modern dormitories, dining halls, and recreational facilities. Living conditions can vary, but camps are equipped with essential amenities.
Benefits: Mining jobs today usually pay very well and offer stable employment, comprehensive benefits packages (medical, dental, pension plans), and opportunities for training and career advancement. Many workers are unionized, which often ensures strong wages and benefits. The presence of a major mine creates significant economic ripple effects, supporting local businesses and services.
Mining companies contribute to local communities through investments in infrastructure, schools, and public services. Workers enjoy competitive salaries, health benefits, retirement plans, and opportunities for career growth. Notably, the average wage for mining jobs in Canada is around 25% higher than the national average wage across all industries.
The Double-Edged Sword: Dangers and Environmental Impact
Mining, while essential, carries inherent risks to both people and the environment.
Dangers to People
Accidents: Rockfalls, equipment malfunctions, explosions (from blasting), fires, and confined spaces pose risks. Modern safety protocols, training, and technology have drastically reduced accident rates, but the industry remains inherently hazardous.
Health Hazards: Historically, dust (leading to lung diseases like silicosis) and exposure to heavy metals were major concerns. Today, stringent ventilation, dust suppression, and air quality monitoring are standard to protect workers.
Dangers to the Environment
Land Disturbance: Excavation creates large open pits or extensive underground workings, altering the landscape and destroying habit.
Water Contamination: A major concern is Acid Mine Drainage (AMD), where sulfide minerals in exposed rock or tailings react with air and water to form sulfuric acid, leaching heavy metals into waterways. Tailings ponds (where waste material from the milling process is stored) also pose risks of spills or leachate.
Air Pollution: Smelters historically released large amounts of sulfur dioxide (SO2), contributing to acid rain and environmental damage. Modern smelters in Northern Ontario (like those in Sudbury) have invested heavily in SO2 capture technology, converting it into sulfuric acid and significantly reducing emissions. Dust from operations can also be an issue.
Waste Management: Massive quantities of waste rock and tailings need to be managed and stored responsibly to prevent environmental contamination.
Habitat Loss: Mine development can lead to the destruction or fragmentation of vital ecosystems.
Energy Consumption: Mining and processing are energy-intensive, contributing to greenhouse gas emissions.
Northern Ontario has a long history of environmental challenges associated with mining, particularly in Sudbury. However, it also presents a true success story in environmental rehabilitation, with massive regreening initiatives transforming once barren landscapes into thriving ecosystems.
Mining Superstitions
No Whistling: Whistling underground is often considered bad luck, as it's believed to challenge or mimic the sounds of the mine's spirits or forces, potentially leading to rockfalls or other accidents.
Never Say "Gold" or "Fire": Some miners avoid directly naming certain elements or dangers, believing it tempts fate.
Lucky Charms/Rituals: Many, even if they don't openly admit it, might have a small ritual or lucky charm they keep before a shift.
Respect for the "Spirit of the Mine": A lingering sense of awe and respect, sometimes bordering on superstition, for the powerful forces within the earth.
The word Nickel is German for "Little Nick", a Kobold in folklore who inhabits copper mines and makes the copper worthless.
Avoid Starting Work on Friday: Starting work on a Friday is believed to be unlucky - not surprisingly.
Copper's Enduring Legacy: Facts about North Ontario Mining
Copper is one of the oldest metals used by humanity. Evidence shows its use dating back over 10,000 years.
Nickel-Copper Symbiosis: In Northern Ontario, copper is almost invariably found in conjunction with nickel, forming some of the most significant polymetallic deposits on Earth.
The Sudbury Basin is one of the richest mineral deposit areas worldwide, containing approximately 70% of the world's nickel reserves alongside its copper.
Pioneering Environmental Reclamation: Sudbury is internationally recognized for its extensive environmental recovery efforts over the past few decades, including widespread regreening programs, which have transformed a landscape once famously described as "moon-like" due to historic logging and smelting practices.
Copper's Versatility: Copper's unique properties – excellent electrical conductivity, thermal conductivity, corrosion resistance, and malleability – make it a versatile element from power generation and transmission to plumbing, electronics and currency.
